small model of 10 ton power press cheap fast speed 10 ton mechanical punching machine

Home / Products / small model of 10 ton power press cheap fast speed 10 ton mechanical punching machine

Product Overview

Press is a kind of general press with fine structure. The press can be widely used in cutting, punching, blanking, bending,riveting and forming.

Products Description



Apolegamic

Gearshift

Air cushion

Automatic feeding

Quickly change device

Automatic mold adjustment

Photoelectric protection











  • Hydraulic overload protection device, Responsive, Reliable action
  • Adopt PLC electrical control system
  • Closed gear transmission, Smooth transmission, Low noise.

Details







Specification

Project
JH21-25
JH21-45
JH21-63
JH21-80
JH21-125
Nominal pressure(t)
250
450
630
800
1250
Nominal force stroke(mm)
3
4
4
5
5
Stroke(mm)
80
100
120
140
160
Number of stroke ofslider(times/min)
100
80
70
60
50
Maximum mold height(mm)
250
270
300
320
370
Mold height adjustment(mm)
50
60
80
80
100
Deep throat(mm)
210
230
300
300
360
worktable size(mm)
400*700
440*810
580*900
580*1000
700*1100
Thickness of worktable(mm)
80
110
110
110
120
Distance between columns(mm)
450
550
560
640
640
