China 400w 600w cheap sheet metal cnc laser cutting machine price

Home / Products / Fiber Laser Cutting Machine / China 400w 600w cheap sheet metal cnc laser cutting machine price

High quality carbon iron aluminum metal stainless steel cutting 1000w 1500w 2000w 3kw cnc fiber laser cutting machine

Specifications

400W 600W sheet metal laser cutting machine
Cutting with a fast speed and high precision
Easy operation
Stable working

China 400w 600w cheap sheet metal cnc laser cutting machine price

Description

Cheap sheet metal CNC laser cutting machine price is the latest laser processing technology of our company for various industries to provide a solution. The machine adopts the latest YAG lamp pumped laser module, low price, no tool wear. The table structure is a cross shape and has a constant light path. It is installed the professional cutting software, realizing the precision cutting. The superior performance of the stepper motor works with the high-precision drive guide structure, so it is of fast processing speed, high efficiency, so that the laser on the move is not affected by the speed, high, low pressure gas blowing system. The cutting effect is better, small cutting slot, smooth section.

China 400w 600w cheap sheet metal cnc laser cutting machine price

Working principle

Cutting is achieved by powerful laser focused on object to cause instant melting and evaporation, with high energy laser. Automatic cutting is controlled by computer. This machine has condensed the technologies of laser, digital, and precise mechanics
High quality carbon iron aluminum metal stainless steel cutting 1000w 1500w 2000w 3kw cnc fiber laser cutting machine

Applications

It is mainly widely applied to almost all metal materials and some non-metal materials, suitable for Cutting & drilling metal materials, like stainless steel plate, stainless steel, carbon steel, galvanized sheet, thin gold plate, thin silver plate and other metal materials and the hollow parts, cutting advertising words & graphics, the spectacles frame, sheet metal IT industry, engine; jewelry industry, metal products, silicon, ceramics, diamond and other non-metallic inorganic material

Cutting & drilling metal materials, like stainless steel plate, stainless steel, carbon steel, galvanized sheet, thin plate, thin plate
cutting advertising words & graphics
Te spectacles frame, sheet metal IT industry, engine; jewelry industry, metal products,
silicon, ceramics, diamond and other non-metallic inorganic material

China 400w 600w cheap sheet metal cnc laser cutting machine price

Specifications

Type of MachineCheap sheet metal CNC laser cutting machine price
Product modelYC50WYC400YC600
Laser Wavelength1064nm

laser power

50W400W600W
Modulating frequency1Hz—30Hz
Marking Range:800mm×1200mm
Pulse width0.1ms—30ms
Spot diameter0.15mm
Positioning precision<±0.02mm
Travel of tableX:150mm   Y: 90mm
Machine power supply220V   50Hz   20A
Cooling methodWater-cooling
Power of the Whole Equipment16-20KW
working conditionstemperature:13°C~29°C, humidity:5%~75%, free of dust and well ventilated
Overall dimension1200×1500×780mm
Machine weight100Kg

Competitive Advantage

Smooth and fine edge or surface and small distortion.
Laser power:  300W/500W
Higher cutting speed and low cost, operation safe and stable function.
Good quality servo motor and gearing system to guarantee precise cutting.
Professional software enables graphic or text to be instantly designed or processed.
Flexible and easy operation.

1000W and 1500W modern fiber laser cutting machine for cutting metal plate

Quick Details

Application: Laser Cutting
Condition: New
Laser Type:YAG
Applicable Material: Acrylic, Crytal, Glass, Leather, Metal, plastic, Plexiglax, Rubber, Stone, Wood
Cutting Thickness: <6mm
Cutting Area: 800mm*1200mm
Cutting Speed: 2100mm/min
CNC or Not: Yes
Cooling Mode: Water Cooling
Graphic Format Supported: AI, PLT, DXF, BMP, DWG, DXP, JPEG,GIF
Certification: CE, ISO, CCC
After-sales Service Provided: Engineers available to service machinery overseas
Laser power(optional): 400w/600w
Modulating frequency: 1Hz-30Hz
Spot diameter: 0.15mm
Positioning precision: <±0.02mm
Pulse width: 0.1ms-30ms
The whole power: 16KW
