High quality Electric Deep drawing single column punching machine small sing-column hydraulic press

Technical Performance

Totally European design, Welded steel frame rigid to deflection moment and high tensile with ST44 A1 material;

Fully enclosed drive, easily accessible for maintenance, eliminates, exposed over hanging parts,slide and bolster tables with T-slots;

Uses a variable flow piston pump - offers high pressure resistance, high velocity, durability and low noise;

Hydraulic pipe system uses integrated circuits - manifold block fits inside the press to reduce piping and oil leaks, easy to maintain, simple and safe. Hydraulic system is from Bosch,Germany;

Guiding device: adopts four cylindrical location guiding to make sure of the steady precision, and it's easy to test and maintain;

Presses operated with automatic one cycle design; two hand push button design for simple and safe operation. Presses which could realize three-operation mode:adjustment, manual and semi-automatic;

PLC press control is flexible and safe. Adjustable proximity switches allows stroke adjustments in seconds;

The Machine is with both hands button and foot switch control: anti-tie down, non-repeat controls with ring guards; conforms to OSHA;

Dual control you can select to use:

# Moveable pedestal height for comfort and ease of operation c/w dual electric palm buttons & extra emergency stop.

# Movable single-hand pedal switch
